| VALQUA No. | Product name | Temperature (°C) | Pressure (MPa) | Product Summary |
|---|---|---|---|---|
| 2010 | NBR Sheet Gasket | -30-120 | 0.5 | Nitrile rubber sheet gasket |
| 2010 | CR Sheet Gasket | -30-120 | 0.5 | Chloroprene rubber sheet gasket |
| 2010 | EPDM Sheet Gasket | -40—150 | 0.5 | Ethylene-propylene rubber sheet gasket |
| 4010 | FKM Sheet Gasket | -15-200 | 0.5 | Fluoro rubber sheet gasket |
| 5010 | VMQ Sheet Gasket | -60—200 | 0.5 | Silicone rubber sheet gasket |
| GF300 | BLACKHYPER | -200—300 | 3.5 | High temperature black sheet gasket using PTFE as a binder |
| SF300 | WHITEHYPER | -200—300 | 3.5 | High temperature white sheet gasket using PTFE as a binder |
| MF300 | BRIGHTHYPER | -200—300 | 3.5 | White sheet gasket using PTFE as a binder applicable for high temperatures and a broad range of uses |
| 6502 | BLACKSUPER | -50—214® | 3 | Black Compressed Fiber Sheet with enhanced heat resistance |
| 6500 | Compressed Non-Asbestos Fiber Sheet for general use | -50—183® | 3 | Compressed Fiber Sheet for general use |
| 6500AC | Anti-corrosion Compressed Non-Asbestos Fiber Sheet | -50—183® | 3 | Anti-corrosion Compressed Fiber Sheet |
| 6503 | White Compressed Non-Asbestos Fiber Sheet for general use | -50—214® | 3 | White Compressed Fiber Sheet with enhanced heat resistance |
| 6503AC | Anti-corrosion white Compressed Non-Asbestos Fiber Sheet | -50—214® | 3 | Anti-corrosion white Compressed Fiber Sheet with enhanced heat resistance |
| 8590TN | NONASUPER | -200—450 | JIS10K JPI Class 150 | An alternative to a high temperature Compressed Fiber Sheet that functions with a low clamp load |
| 7010 | VALFLON | -50—100 | 1 | Pure PTFE sheet gasket |
| 7010-EX | NEW VALFLON | -50—150 | 1 | PTFE sheet gasket with improved creep resistance |
| 7GP66 | VALFLON Soft Sheet Gasket | -240—260 | 2 | Expanded PTFE gasket with mesh construction |
| 7020 | VALQUALON | -200—200 | 4 | Low creep type PTFE Gasket reinforced with inorganic filler |
| 7026 | BLACK VALQUALON | -200—200 | 4 | Low creep type PTFE Gasket reinforced with carbon filler |
| N7030(N) Series | VALFLON Envelope Gasket | -100—150 | 1.5 | Fluorocarbon resin envelope gasket using Compressed Fiber Sheet in the core |
| N7030(S) Series | VALFLON Envelope Gasket | -100—200 | 2 | Fluorocarbon resin envelope gasket using Compressed Fiber Sheet and felt in the core |
| N7030(H) Series | VALFLON Envelope Gasket | -100—260 | 3 | Fluorocarbon resin envelope gasket using expanded graphite sheet and felt in the core (high temperature use) |
| 7GS66A | CORDSEAL <Soft> | -240—260 | 5 | Free size PTFE string type material that can be installed in arbitrary shapes as required |
| VF-30 | VALQUAFOIL Sheet Gasket | -240—400 | 2 | Expanded graphite gasket |
| VF-35E | VALQUAFOIL Sheet Gasket with thin metallic sheet | -240—400 | 5 | Expanded graphite gasket reinforced with a stainless steel foil |
| VFT-30 | VALQUAFOIL Sheet Gasket | -240—300 | 2 | Expanded graphite gasket laminating PTFE sheets on both sides of No.VF-30 |
| VFT-35E | VALQUAFOIL Sheet Gasket with thin metallic sheet | -240—300 | 5 | Expanded graphite gasket laminating PTFE sheets on both sides of No.VF-35E |
| N214 | VALQUATEX Gasket | 400 | 0.1 | Gasket made of rubber coated glass fiber fabric |
| N314 | VALQUATEX Gasket | 800 | 0.1 | Gasket made of rubber coated ceramic fiber fabric with metallic wire (heat resistant) |
| 8590 Series | CLEANTIGHT | -200—500 | 30 | Spiral wound gasket using non-asbestos inorganic paper as filler |
| 6590 Series | BLACKTIGHT | -270—450 | 30 | Spiral wound gasket using expanded graphite tape as filler |
| 7590 Series | WHITETIGHT | -260—300 | 20 | Spiral wound gasket using PTFE tape as filler |
| M590 Series | Mica filler product | 750 | 30 | Spiral wound gasket using mica as filler |
| N510 Series | Non-Asbestos Corrugated Metal Jacketed Gasket | Depending on the material used | 7 | Concentric corrugated gasket with a metal sealing element coating the soft filler material |
| N520 Series | Non-Asbestos Flat Metal Jacketed Gasket | Depending on the material used | 7 | Flat gaskets with a metal sealing element coating the soft filler material |
| 560 Series | Flat Metal Gasket | Depending on the material used | 14 | Flat metal gaskets are either cut or machined from flat plates, round rods, forging metals, etc |
| 540 Series | Serrated Metal Gasket | Depending on the material used | 14 | Concentric grooved metal gasket |
| 550 Series | Ring Joint Gasket | Depending on the material used | 45 | A gasket machined from metal (usually oval or octagonal in cross-section) and used in conjunction with ring-joint flanges |
